PioNext Mini Dental LCD 3D Printer
R44999,00
Compact chairside dental LCD 3D printer with integrated printing and curing, 9K resolution, 18 µm XY accuracy, dual 385/405 nm wavelength support, heated chamber and WiFi/USB connectivity.
Please register or log in to place orders.
PioNext Mini Dental LCD 3D Printer
The PioNext Mini is a compact all-in-one dental LCD 3D printer designed for chairside and laboratory workflows where fast, accurate production is needed in a small footprint.
Key Features
- All-in-one workflow: integrated printing and curing in one compact unit.
- 9K LCD resolution: 8520 × 4320 px for highly detailed dental output.
- 18 µm XY accuracy: suitable for detailed restorations, guides, splints and appliances.
- Dual wavelength: supports 385 nm and 405 nm resin workflows.
- Heated chamber: up to 35°C for improved resin flow and smoother layers.
- Leveling-free operation: designed to reduce setup time.
- Dual resin vats included: useful for switching workflows or materials.
- WiFi and USB: flexible data transmission options.
Dental Applications
- Crowns, veneers and inlays
- Surgical guides
- Orthodontic models
- Splints and night guards
- Retainers
- Removable dentures
Technical Specifications
| Printing technology | LCD resin printing |
|---|---|
| Build volume | 80 × 70 × 80 mm |
| Resolution | 9K / 8520 × 4320 px |
| XY accuracy | 18 µm |
| Layer thickness | 0.01 – 0.10 mm |
| Maximum print speed | 60 mm/h |
| Light source wavelength | 385 nm / 405 nm |
| Touchscreen | 3.97-inch capacitive colour touchscreen |
| Connectivity | USB / WiFi |
| Slicer software | PioCreat Box / CHITUBOX Dental |
| Machine size | 200 × 170 × 241 mm |
| Package size | 310 × 307 × 340 mm |
| Weight | 4.86 kg net / 6.8 kg gross |
| Power | 120 W |
| Input voltage | 100–240 V, 50/60 Hz |
| Warranty | 12 months manufacturer warranty |
| Weight | 4,86 kg |
|---|---|
| Dimensions | 20 × 17 × 24,1 cm |
| Brand | PioCreat |
| Printing Technology | LCD Resin Printing |
| Build Volume | 80 × 70 × 80 mm |
| Resolution | 9K / 8520 × 4320 px |
| XY Accuracy | 18 µm |
| Layer Thickness | 0.01 – 0.10 mm |
| Light Source Wavelength | 385 nm / 405 nm |
| Connectivity | USB, WiFi |
| Touchscreen | 3.97-inch capacitive colour touchscreen |
| Warranty | 12 months manufacturer warranty |
